M306NKT-EPB User’s Manual

5. Troubleshooting

REJ10J0519-0200 Rev.2.00 Oct. 16, 2006

Page 99 of 104



(3) Errors Occur at Emulator Debugger Startup

Table 5.3 Checkpoints of errors at debugger startup

Error Checkpoint

ERROR 16224:

Target MCU is uncontrollable.
Execute the RESET command.

(1) Check that the NQPACK etc. mounted on the user system is soldered

properly.

(2) Check that the connector is installed properly to the user system.
(3) In memory expansion mode or microprocessor mode, check pins

RDY# and HOLD# are at “H” level.
