M306NKT-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0519-0200 Rev.2.00 Oct. 16, 2006 Page 64 of 104
(3) When DATA ACCESS is selected
1. Window for setting the address
Setting the address
Set in the Address tab.
You can set eight conditions, e.g., a specified address, a specified
address range, etc.
After finishing the setting the address, set the data.
2. Window for setting data
Setting data
Set in the Data tab.
You can set eight conditions, e.g., a specified data, a specified data
range, etc.
Setting the access condition
You can set three conditions, e.g., read, write, and read/write. When
you have finished setting the data and access condition, click OK.
