4.2 Access Timing
Because this product emulates some ports, access timings are different from those of the actual MCUs. Chapters 4.2.1
(Vcc=5V) and 4.2.2 (Vcc=3V) describe the access timing using this product.
4.2.1 Operation Timing of Memory Expansion Mode and Microprocessor Mode (Vcc=5V)
(1) Separate Bus Timing
Table 4.2 and Figure 4.1 show the bus timing in memory expansion mode and microprocessor mode (3-wait, accessing
external area).
Table 4.2 Memory expansion mode and microprocessor mode (3-wait, accessing external area)
Actual MCU
[ns]
This product
[ns]
Symbol Item
Min. Max. Min. Max.
td(BCLK-AD)
Address output delay time
25
See left
th(BCLK-AD)
Address output hold time (BCLK standard)
4
See left
th(RD-AD)
Address output hold time (RD standard)
0
-2
th(WR-AD)
Address output hold time (WR standard)
(*2)
See left
td(BCLK-CS)
Chip-select output delay time
25
See left
th(BCLK-CS)
Chip-select output hold time (BCLK standard)
4
See left
td(BCLK-ALE)
ALE signal output delay time
25
See left
th(BCLK-ALE)
ALE signal output hold time
-4
See left
td(BCLK-RD)
RD signal output delay time
25
See left
th(BCLK-RD)
RD signal output hold time
0
See left
td(BCLK-WR)
WR
signal
output
delay
time
25 27
th(BCLK-WR)
WR signal output hold time
0
See left
td(BCLK-DB)
Data output delay time (BCLK standard)
40
See left
th(BCLK-DB)
Data output hold time (BCLK standard)
4
See left
td(DB-WR)
Data output delay time (WR standard)
(*1)
See left
th(WR-DB)
Data output hold time (WR standard)
(*2)
See left
*1 Calculated by the following formula according to the frequency of BCLK.
(
)
40
)
(
10
5
.
0
9
−
×
−
BCLK
f
n
[ns] n: "3" for 3 wait
*2 Calculated by the following formula according to the frequency of BCLK.
10
)
(
10
5
.
0
9
−
×
BCLK
f
[ns]
