M306NKT-EPB User’s Manual 1. Outline
REJ10J0519-0200 Rev.2.00 Oct. 16, 2006 Page 18 of 104
1.4 Specifications
Tables 1.5 and 1.6 list the specifications of the M306NKT-EPB.
Table 1.5 Specifications of the M306NKT-EPB (1/2)
Applicable MCU M16C/6N Group
M16C/6N4, M16C/6N5, M16C/6NK, M16C/6NL, M16C/6NM, M16C/6NN
Applicable MCU mode Single-chip mode
Memory expansion mode
Microprocessor mode
Maximum operating frequency 24MHz (when using PLL)
Applicable power supply 3.0--5.5V
Emulation memory (1) 512KB + 4KB for internal ROM of MCU
0F000h--0FFFFh,
80000h--FFFFFh,
maximum operating frequency: 24MHz, 0 wait
* When "Disable the Internal Flash ROM" is checked in the MCU tab of the
emulator debugger's MCU Setting dialog box, it is 10MHz.
(2) 31KB for internal RAM
00400h--07FFFh, maximum operating frequency: 24MHz, 0 wait
(3) CS3*--CS0* area (Possible to allocate by 4KB)
- Maximum operating frequency (at 5.0V) 0 wait: 7.0MHz
1 wait: 20.0MHz
2 wait, 3 wait: 24.0MHz
- Maximum operating frequency (at 3.0V) 0 wait: 6.0MHz
1 wait: 17.0MHz
2 wait, 3 wait: 24.0MHz
Clock oscillator X
IN
-X
OUT
(1 to 16MHz):
Internal oscillator circuit board
Switchable to external oscillator input or internal generator circuit
X
CIN
-X
COUT
(32.768kHz):
Internal oscillator circuit board
Switchable to external oscillator input
Basic debugging functions - Download
- Address match break (max. 8 points)
- Software break (max. 64 points)
- Program execution/stop (allows free-run execution supporting software breaks)
- Memory reference/setting (reference/setting C-variables, run-time execution)
- Register reference/setting
- Disassemble display
- C-level debugging, etc.
Real-time trace function - 256K-cycle bus information recordable (Bus, external trigger, time stamp)
- 5 trace modes supported (Break/Before/About/After/Full)
- Can be recorded ON/OFF by events
Real-time RAM monitor function - 4,096 bytes (256 bytes x16)
- Data/last access result
Hardware break function 8 points (Execution address, bus detection, interrupt, external trigger signal)
Execution time measurement function Time between program start and stop
Maximum/minimum/average execution time and pass count of specified four zones.
Count clock: Equal to MCU Clock or 16MHz
C0 coverage 8,192KB (256KB x 32 blocks)
External trigger input/event output External trigger input (MCU-dependent-voltage CMOS level x8) or event output
(break x1, event x7)
