M306NKT-EPB User’s Manual 4. Hardware Specifications
REJ10J0519-0200 Rev.2.00 Oct. 16, 2006 Page 86 of 104
Table 4.8 Electrical characteristics of the 74HC4066
Standard values
Symbol Item Condition
Min. Standard Max.
Unit
R
ON
ON resistor Vcc=4.5V - 96 170
ΔR
ON
ON resistor difference Vcc=4.5V - 10 -
Ω
I
OFF
Leak current (Off) Vcc=12.0V - - ±100
I
IZ
Leak current (On, output: open) Vcc=12.0V - - ±100
nA
Table 4.9 Electrical characteristics of port emulation FPGA
Standard values
Symbol Item Condition
Min. Standard Max.
Unit
V
IH
"H" level input voltage 2.0 - 5.5
V
IL
"L" level input voltage -0.5 - 0.8
I
OH
=-8mA DC,
Vcc=4.75V
2.4 - -
V
OH
"H" level output voltage
I
OH
=-8mA DC,
Vcc=3.00V
2.4 - -
I
OL
=8mA DC,
Vcc=4.75V
- - 0.45
V
OL
"L" level output voltage
I
OL
=8mA DC,
Vcc=3.00V
- - 0.45
V
I
I
Leak current VI=Vcc or GND -10 - 10 µA
I
OZ
Leak current (Tristate) Vo=Vcc or GND -40 - 40 µA
C
IN
I/O pin input capacitance
V
IN
=0V,
f=1.0MHz
- - 8 pF
