51
Basic connections and settings
If you are using the UA-25 from an ASIO2.0-compatible software in Advanced
mode , the UA-25’s direct monitor switch can be controlled automatically from the
software.
1. Open the control panel.
Windows XP
Click the Windows start menu, and from the menu, select Control Panel .
* Click “Switch to Classic View” to select Classic View on your computer. If you’re not
in Classic View, the EDIROL UA-25 icon won’t be shown.
Windows 2000/Me/98
Click the Windows Start button, and from the menu that appears, select Settings
| Control Panel .
* In Windows Me, click “View all Control Panel options.”
Mac OS
Open the ASIO Control Panel from the Audio Settings dialog box of your ASIO-
compatible software. The name of the Audio Settings dialog box and the
procedure for opening the ASIO Control Panel will differ depending on your
software. For details, refer to the operation manual for your software.
2. Double-click “EDIROL UA-25.”
The EDIROL UA-25 Driver Settings dialog box will appear.
3. Make the following settings.
Check the
“Use ASIO Direct Monitor” check box.
4. Click [OK] to close the driver settings dialog box.
* Depending on your software, there may also be an ASIO Direct Monitor setting among
the audio settings of your software. For details, refer to the operation manual for your
software.
* When using ASIO Direct Monitor, monitoring may switch on/off at unexpected times,
depending on the software settings and on the recording procedure. If this occurs, uncheck
the check box in step 3 to disable ASIO Direct Monitor.
Using ASIO direct monitor
