Driver installation and settings (Windows)
1
With the UA-25 disconnected, start up Windows.
Disconnect all USB cables except for a USB keyboard and
USB mouse (if used).
If you are using virus checking or similar software, be sure
to exit it as well.
2
Exit all currently running software (applications).
Also close any open windows. If you are using virus
checking or similar software, be sure to exit it as well.
3
Prepare the CD-ROM.
Insert the CD-ROM into the CD-ROM drive of your
computer.
4
Click the Windows Start button. From the menu that
appears, select Run... .
The “Run...” dialog box will appear.
5
In the dialog box that appears, input the following into the
“Open” field, and click [OK] .
(drive name) : \Driver\Me98\SETUPINF.EXE
The SetupInf dialog box will appear.
You are now ready to install the driver.
* In the explanatory example shown here, the drive name is
given as “D:” . The drive name “D:” may be different for your
system. Specify the drive name of your CD-ROM drive.
6
Set the UA-25’s ADVANCE (mode select) switch to the
ON position.
7
Use the USB cable to connect the UA-25 to your
computer .
The driver will be installed automatically.
Windows Me/98 users
To check the drive name
In the Windows desktop,
double-click the My Computer
icon. In the window that
appears, check the drive name
of the CD-ROM drive into
which you inserted the CD-
ROM in step3.
The drive name is the (D:) or
(E:) displayed by the CD-ROM
drive
.
This unit is equipped with a
protection circuit. A brief
interval (a few seconds) after
connecting the USB cable is
required before the unit will
operate normally.
If a message recommends that
you restart Windows, restart
Windows as directed.
