Roland UA-25 - Manual (Page 29)

29
Driver installation and settings (Windows)
Windows 98 users
1
Open the Multimedia Properties dialog box.
1. Click the Windows Start button, and from the menu
that appears, select Settings | Control Panel .
2. In Control Panel , double-click the Multimedia icon
to open the “Multimedia Properties” dialog box.
2
Click the Audio tab.
3
Specify the “Preferred
device” .
Click the Playback field
and Recording field,
make the following
selections from the list
that appears, and click
[Apply] .
4
Click the MIDI tab.
fig.2-29_30
5
Specify the “MIDI
output” .
Add a check mark to
[Single instrument] ,
click [EDIROL UA-25
MIDI OUT] in the list,
and click [Apply] .
6
Close the Multimedia
Properties dialog box.
Click [OK] to complete the settings.
This completes the audio and MIDI input/output settings.
Proceed to
“Checking that you hear sound” (p. 31).
Playback EDIROL UA-25
Recording EDIROL UA-25
