21
Driver installation and settings (Windows)
8
Click the Windows Start button. From the menu that
appears, select “Run...”
The “Run...” dialog box will appear.
9
In the dialog box that appears, input the following into the
“Open” field, and click [OK] .
fig.05-5_30
(drive name) : \Driver\XP_2k\SETUPINF.EXE
* In the explanatory example shown here, the drive name is
given as “D:”. The drive name “D:” may be different for your
system. Specify the drive name of your CD-ROM drive.
The SetupInf dialog box will appear.
You are now ready to install the driver.
10
Set the UA-25’s ADVANCE (mode select) switch to the
ON position.
11
Use the USB cable to connect the UA-25 to your
computer .
To check the drive name
In the Windows desktop,
double-click the My Computer
icon. In the window that
appears, check the drive name
of the CD-ROM drive into
which you inserted the CD-
ROM in step7.
The drive name is the (D:) or
(E:) displayed by the CD-ROM
drive
.
This unit is equipped with a
protection circuit. A brief
interval (a few seconds) after
connecting the USB cable is
required before the unit will
operate normally.
If the “File signature verification” (Step 4) setting was not set to “Ignore”, a
“Digital Signature Not Found”
dialog box will appear.
If “File signature verification” is set to “Warn”
1. Click [Yes].
2. Continue the installation.
If “File signature verification” is set to “Block”
1. Click [OK].
2. When the “Found New Hardware Wizard” appears,
click [Finish].
3. Return to step 1 (p. 20) and re-install the driver from the beginning of the
procedure.
