100
Effect List
9: STEPFLANGER (Step Flanger)
Shifts the pitch of the flanged sound in stages. The pitch shift cycle can also be specified in note length corresponding to the
tempo. It is also possible to automatically adjust the tempo to that of the wave that is played back. (Effect synchronization (Phrase
Sync) -> p. 116)
In addition, if you press the PAGE buttons, “Knob,” “Velo” and “Pedal” are displayed. You can then select the parameters to be
controlled with the EFFECTS CONTROL knob, the strength (velocity) used in hitting a playing surface, and the expression pedal.
Parameter Value Descriptions
Sync OFF,
FIXED,
PHRASE Setting for synchronization of pitch shift (Effect synchronization (Phrase Sync) -> p.
116)
OFF: Not synchronized
FIXED: Synchronized to Tempo
PHRASE: Synchronized to the tempo of the wave that is played back
Tempo 20–260 Pitch shift tempo (* Configurable when Sync is FIXED or PHRASE)
* You can also define the tempo by controlling the intervals at which you hit a pad
or depress a foot switch. (Tap Tempo: Ctrl SW in CONTROL SW in Setup Edit
-> p. 79)
Beat 3 3 3 Note length in pitch shift (* Configurable when Sync is FIXED or PHRASE)
StepRate 0–127 Pitch shift cycle (* Configurable when Sync is OFF)
Depth 0–127 Vibration depth
Rate 0–127 Vibration cycle
Resonance 0–127 Degree of peculiarity of the flanged sound
Manual 0–127 Pitch of the flanged sound
Balance D100:0W–D0:100W Level balance between the original sound (D) and the flanged sound (W)
Value Parameters controlled with Knob and Pedal
(See the table above for details.) Descriptions
OFF — —
TEMPO Tempo * Configurable when Sync is FIXED or PHRASE
STEPRATE StepRate * Configurable when Sync is OFF
DEPTH Depth —
RATE Rate —
RESONANCE Resonance —
BALANCE Balance —
MANUAL Rate, Manual Vibration is stopped to control the pitch of the flanged
sound.
Value Parameters controlled with Velo
(See the table above for details.) Descriptions
OFF — —
STEPRATE StepRate * Configurable when Sync is OFF
DEPTH Depth —
RATE Rate —
RESONANCE Resonance —
BALANCE Balance —
MANUAL Rate, Manual Vibration is stopped to control the pitch of the flanged sound.
