Renesas Emulation Probe M306V8T-EPB User Manual
Page 85
M306V8T-EPB User’s Manual
5. Troubleshooting
REJ10J0777-0100 Rev.1.00 2005.08.01
Page 85 of 90
(3) Errors Occur at Emulator Debugger Startup
Table 5.3 Checkpoints of errors at debugger startup
Error Checkpoint
Target MCU is uncontrollable.
(1) Check that the NQPACK etc. mounted on the user system is soldered
properly.
(2) Check that the connector is installed properly to the user system.
(3) In memory expansion mode or microprocessor mode, check pins
RDY* and HOLD* are at “H” level.
