M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0777-0100 Rev.1.00 2005.08.01 Page 55 of 90
3.3 Hardware Breakpoint Setting Window
(1) Breakpoint setup dialog box
1. Opening the hardware breakpoint setup dialog box
Hardware Break Point
Clicking this button opens the hardware breakpoint setup
dialog box.
2. Hardware Break Point Setting Window in initial state
H/W breakpoint Setting Window in initial
state
Select the “Enable H/W Break” check box, and this
break function will be enabled, allowing you to set
hardware breakpoints.
Setting Break Event
Click the event line at which you want set a break
event.
