M306V8T-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0777-0100 Rev.1.00 2005.08.01 Page 51 of 90
3.1.3 Checking Connections of the Emulator System
Checking connections of the emulator
system
When the emulator debugger is connected correctly to
the emulator after you’ve finished setting up the Init
dialog box and the MCU Setting dialog box, you will see
a message “Connected” displayed on the Debug tab of
the Output window.
