5 external dimensions, 1 external dimensions of the emulation probe – Renesas Emulation Probe M306V8T-EPB User Manual
Page 75
M306V8T-EPB User’s Manual
4. Hardware Specifications
REJ10J0777-0100 Rev.1.00 2005.08.01
Page 75 of 90
4.5 External Dimensions
4.5.1 External Dimensions of the Emulation Probe
Figure 4.5 shows external dimensions of the M306V8T-EPB.
Figure 4.5 External dimensions of the emulation probe
RENESAS
665
320
290
55
55
140
35
Unit: mm
