Weight The weight of a trunk to be selected in a trunk balance group
for an outgoing call.
3.3 Mass Extension Adding
The Mass Extension Adding Management page helps the administrator to add many extensions and
assign users for these extensions under a usergroup and a device. After finishing configuration, click
at the bottom of the homepage to take the configuration effect.
Note: Make sure the range of extension numbers does not exist in Extension of IP Phone or user Login
ID, or the configuration will fail to continue.
Step 1: Add User & Extension
1. Enter the digits for the starting extension.
2. Click a number in the Number of EXT list for the mass extension adding.
3. Click a usergroup in the USERGROUP list.
4. Select enable to allocate voicemail account for the extension.
5. Click an IP phone device in the DEVICE list.
6. Select to enable Try-Peer-to-peer RTP. If click INVITE or UPDATE, IP PBX will attempt to notify
the two peers in a conversation to try peer-to-peer RTP transmission.
7. Click a usergroup in the Pickup Group list.
8. Select Include Reachables check box to enable pickup calls that belong to other usergroup
which is configured in Reachable User Groups of the selected usergroup.
9. Choose preferred DTMF mode for extensions. Currently supported types include RFC2833, SIP
INFO and Inband.
10. Click ADD, and IP PBX will start to add these extensions automatically.
11. Click Back to the homepage.
21
