Important:

• When a live image from the audio assigned camera

channel is displayed on a single screen on monitor 2,
audio will be heard. When displaying on a multi-screen,
audio will not be heard.

• When images from the audio assigned camera channel

are displayed on a single screen, recorded audio will
be heard. When displaying on a multi-screen, recorded
audio will not be heard.

• Audio will be recorded regardless of whether you are

displaying on a single screen or a multi-screen.

[Emergency REC] Perform the settings for
emergency recording

Perform the settings for emergency recording such as
the recording time or recording rate for emergency
recording.
Refer to page 21 for further information about emer-
gency recording.

• [Resolution]

Select a recording resolution from the following.
FRAME 3D ON: High resolution (720 x 480), with cam-

era shake compensation

FRAME 3D OFF: High resolution (720 x 480)
FIELD: Standard resolution (720 x 240)
SIF: Low resolution (360 x 240)

• [Recording Time]

Perform the settings for the recording time and record-
ing action for emergency recording.
The following are available for the recording time.
1 s - 10 s (in 1 second intervals)
20 s/30 s
1 m - 10 m (in 1 minute intervals)
20 m/30 m/40 m/50 m/60 m
MANUAL: Recording will continue while the external

switch is being held down.

CONTINUE: Recording will not stop until the ALARM

RESET button on the front panel of the unit is
pressed.

• [Recording Rate and Quality]

Perform the settings for the recording rate and image
quality for emergency recording.
The following are available for the recording rate.
OFF/1 ips/2 ips/3 ips/5 ips/6 ips/7.5 ips/10 ips/15 ips/
30 ips/60 ips

Important:

• When OFF is selected for a specified camera channel,

images from a camera channel set to OFF will not be
recorded.

• When "FRAME 3D ON" or "FRAME 3D OFF" is selected,

the total recording rates of CAM 1 - CAM 16 (for the
WJ-HD316) must be less than 30 ips.

• When "FIELD" is selected, the total recording rates of

CAM 1 - CAM 16 (for the WJ-HD316) must be less than
60 ips.

• When "SIF" is selected, the total recording rates of CAM

1 - CAM 16 (for the WJ-HD316) must be less than 120
ips.

• When "FRAME 3D ON", "FRAME 3D OFF" or "SIF" is

selected, it is impossible to select 60 ips.

The following are available for the image quality.
SFA/SFB: Top quality (SUPER FINE)
FQA/FQB: High quality (FINE)
NQA/NQB: Standard quality (NORMAL)
EXA/EXB: Low quality (EXTENDED)

**A is suitable for less dynamic images.
**B is suitable for more dynamic images.

•

[Auto Copy]
Select ON or OFF to set whether or not to automatically
copy images recorded by emergency recording onto
the copy area on the built-in hard disk or DVD-RAM
disk.

Important:

When OFF is selected for "Auto Copy" on "Basic setup"
of "System", the auto copy function will not work after
emergency recording even though ON is selected for
this setting. Select "HDD", "COPY 1" or "COPY 2" for
"Auto Copy".

Recording

Event

Schedule

System

Display

Comm

Switcher

SETUP MENU

LIVE

Maintenance

REC Setup

Emergency REC

■

Resolution

■

Recording Time

■

Recording Rate and Quality

■

Auto Copy

10s

FIELD

CAM1

RATE

QUALITY

RATE

QUALITY

CAM2
CAM3
CAM4
CAM5
CAM6
CAM7
CAM8

CAM9
CAM10
CAM11
CAM12
CAM13
CAM14
CAM15
CAM16

3ips
3ips
3ips
3ips
3ips
3ips
3ips
3ips

SFA
SFA
SFA
SFA
SFA
SFA
SFA
SFA

OFF
