[Screenshot 4]
The cursor moves to the "PRESET" in "STEP 1".
b Rotate the jog dial to select a preset position number
for which image is displayed in "STEP 1" from the follow-
ing.
1 - 64: Moves to the selected preset number.
--: Does not move to the preset position.
n Select "DWELL" in "STEP 1" using the arrows button.
[Screenshot 5]
The cursor moves to"DWELL" in "STEP 1".
m Rotate the jog dial to select an interval time to go to the
next sequential step from 1 - 30 seconds (in 1 second
intervals).
The sequence step is skipped when "0 s" is selected.
Repeat steps 2 and 7 to set for other sequence steps.
, Move the cursor to "OK" using the arrows button and
press the SET button.
→ The settings for the sequential display are set and
the sequence setting menu closes.
Notes:
• If you move the cursor to "CANCEL" in step 8 and
press the SET button, the setting is canceled and
the sequence setting menu closes.
• The settings for the sequential display will not be
applied until the SET button is pressed after select-
ing "OK" using the arrows button in step 8.
● Sequence Timing
Select an image switching way from the following.
INT: Switches images according to the settings for the live
sequence.
EXT: Switches images by signals from an external device.
MON 2: Match with the image switching timing of the live
sequence on monitor 2.
● Auto Skip
Select ON of OFF to determine whether or not to skip the
camera channel without supplying the video input signal
because it is not connected, etc.
ON: Skips a channel if it is not connected.
OFF: Displays a black screen for a channel not connected.
● Login Screen
Select a camera image to be displayed during the login
procedure from the following.
CAM1 - 16: Displays an image from the selected camera
channel.
QUAD1 - 4: Displays images from the camera channels 1 -
4 on a 4-split screen.
QUAD5 - 8: Displays images from the camera channels 5 -
8 on a 4-split screen.
QUAD9 - 12: Displays images from the camera channels 9
- 12 on a 4-split screen.
QUAD13 - 16: Displays images from the camera channels
13 - 16 on a 4-split screen.
7 SCREEN: Displays images from the camera channels 1 -
7 on a 7-split screen.
9 SCREEN 1 - 9: Displays images from the camera chan-
nels 1 - 9 on a 9-split screen.
9 SCREEN 10 - 16 (only for the WJ-HD316): Displays
images from the camera channels 10 - 16 on a 9-split
screen.
10 SCREEN: Displays images from the camera channels 1
- 10 on a 10-split screen.
13 SCREEN: Displays images from the camera channels 1
- 13 on a 13-split screen.
16 SCREEN: Displays images from the camera channels 1
- 16 on a 16-split screen.
--: No camera image will be displayed (black screen)
● Secret View
The secret view is a function to display a black screen on
monitor 1 when camera images are displayed with a single
screen on monitor 2. Select ON or OFF to determine
whether to enable or disable the secret view function.
ON: Enables the secret view function. (Camera image dis-
played with a single screen on monitor 2 will be dis-
played while monitor 1 has a black screen.)
OFF: Disables the secret view function.
