[Screenshot 4]
The "DISK SELECT" menu will be displayed.
When using the RAID 5 function, the "UNIT SELECTION"
menu will be displayed.
m Move the cursor to a desired hard disk (unit) to be for-
matted (initialized) using the arrows button and press
the SET button.
[Screenshot 5]
"THE SETTING METHOD" menu will be displayed.
, Select a setting method for each recording area from
the following using the arrows button (A B) and press
the SET button.
Auto Setup: Assigns the same proportion for each
recording area as the proportion of the existing
hard disks. (
→ step 9)
All Copy Area: Sets the whole selected hard disk (unit)
as the copy area. ( → step 9)
All Pre REC Area: Sets the whole selected hard disk
(unit) as the pre-recording area. ( → step 10)
Detailed Setup: Sets each recording area individually.
( → step 11)
Important:
When the built-in hard disk of this unit is selected, "All
Pre REC Area" is not available.
[Screenshot 6]
The confirmation menu of the set recording area will be dis-
played.
. Confirm the capacity of the set recording area and
press the SET button.
→ The confirmation dialog window will be displayed.
(
→ step 13)
