The cursor will move to the selected cell for entry of the ON
or OFF time for summer time.
c Rotate the jog dial to enter the ON or OFF time (year,
month, date) for summer time.
v Move the cursor to "OK" and press the SET button.
→ The ON and OFF time for summer time will be
applied and the "Summer Time (Day Light Saving)
Table" will be closed.
Notes:
• When you move the cursor to "CANCEL" in step 4
and press the SET button, the setting will be can-
celed and the "Summer Time (Day Light Saving)
Table" will be closed.
• The settings for summer time will not be applied
until the SET button is pressed after moving the cur-
sor to "OK" in the step 4.
e
[User Registration] Registration of user who
operates this unit
Register user information such as user name and pass-
word.
After filling out the user information, move the cursor to
"SET" at the lower right of the menu and press the SET
button to complete registration.
● User Name
Enter 4-32 alphanumeric characters for a user name.
The same method is used to enter, insert and delete char-
acters as for attaching text information to images. Refer to
page 55.
● Password
Enter 4-32 alphanumeric characters for password.
The same method is used to enter, insert and delete char-
acters as for attaching text information to images. Refer to
page 54.
● Level
Select a user level from the following.
Setting of operable functions in each level is described in
"User Level" (Refer to page 121).
LV1/LV2/LV3
● Priority
Assign priority (1 (lowest) to 16 (highest)) to users.
● Default Screen
Select a camera image to be displayed during the logon
procedure from the following.
CAM1 - 16: Displays an image from the selected camera
channel.
QUAD1 - 4: Displays images from the camera channels 1 -
4 on a 4-split screen.
QUAD5 - 8: Displays images from the camera channels 5 -
8 on a 4-split screen.
QUAD9 - 12: Displays images from the camera channels 9
- 12 on a 4-split screen.
QUAD13 - 16: Displays images from the camera channels
13 - 16 on a 4-split screen.
7 SCREEN: Displays images from the camera channels 1 -
7 on a 7-split screen.
9 SCREEN 1 - 9: Displays images from the camera chan-
nels 1 - 9 on a 9-split screen.
9 SCREEN 10 - 16 (only for the WJ-HD316): Displays
images from the camera channels 10 - 16 on a 9-split
screen.
10 SCREEN (only for the WJ-HD316): Displays images
from the camera channels 1 - 10 on a 10-split screen.
13 SCREEN (only for the WJ-HD316): Displays images
from the camera channels 1 - 13 on a 13-split screen.
16 SCREEN (only for the WJ-HD316): Displays images
from the camera channels 1 - 16 on a 16-split screen.
SEQ: Images will be displayed in the sequential display.
● Camera Partitioning
Select a controllable range for each camera channel from
the following.
View/Operate: Displaying live images and operating cam-
era are possible.
View: Displaying live images is possible but cameras can-
not be operated.
--: Both displaying live images and operating the camera
are impossible.
