● Parity
Select a method to check a transmission error at communi-
cation from the following.
NONE: No parity check
EVEN: Even parity
ODD: Odd parity
● Stop Bit
Select a stop bit from the following.
1/2 bit
● Retry Timing
Select a retransmission interval for when data reception is
not confirmed from the following.
OFF/100 ms/200 ms/400 ms/1 000 ms
t
[NW Setup 1] Basic network settings
Perform the following basic network settings to operate
this unit using a PC via a network such as a LAN.
● HTTP Port Number
Specify the HTTP port number to be used to transfer
images from this unit. It is not necessary to change it for
normal use.
● User Authentication
Select ON and OFF whether or not to activate user authenti-
cation at the time of access from a PC to this unit.
When ON is selected, the user authentication window will
be displayed at the time of access from a PC.
The top page will be displayed if the entered user name
and password are registered.
ON: Activates user authentication.
OFF: Does not function.
Note: It is recommended to select ON for the user authenti-
cation for security.
● Host Authentication
Select ON or OFF whether or not to restrict access by IP
addresses at the time of access from a PC to this unit.
When ON is selected, only PCs with registered IP address
can access this unit
Using the user and host authentication together will
enhance the network security.
ON: Activates host authentication.
OFF: Does not function.
● Line Speed
The line speed will be displayed.
It is impossible to change the value for this setting.
● Live Video Quality
Image quality level for a live (FQB: high quality) will be dis-
played.
It is impossible to change the value for this setting.
y
[NW Setup 2] Network connection settings
Perform the following network connection settings to
operate this unit using a PC via a network such as a
LAN.
● DHCP
Select ON or OFF whether or not to use the DHCP server.
When obtaining IP addresses, net mask and a gateway
address from the DHCP server, set to ON.
If not, set to OFF and enter those addresses manually.
ON: Uses the DHCP server.
OFF: Does not use the DHCP server.
● IP Address
Enter an IP address when OFF is selected for "DHCP".
For this unit, enter 4 units of the decimal number (0-255).
● Subnet Mask
Enter a subnet mask according to the network configuration
when OFF is selected for "DHCP".
● Gateway
Enter the gateway address according to the network con-
figuration when OFF is selected for "DHCP".
● DNS
Select "MANUAL" or "AUTO" to enable searching an IP
address by its host name using DNS. When "OFF" is select-
ed for "DHCP" (no use of the DHCP server), select "MANU-
AL" and enter the domain name and the DNS server
address. If "ON" is selected for "DHCP" (use of the DHCP
server), select "AUTO". When DNS is not used, select "OFF".
When "MANUAL" is selected for DNS, enter the DNS server
address for "Primary" and "Secondary".
