120
● Host IP Address
Enter the IP address. Move the cursor to "Host IP Address"
and rotate the jog dial to enter the IP address. For this unit,
enter 4 units from the decimal numbers (0-255).
● Level
Select a user level from the following.
Setting of operable functions for each level is described in
"User Level" (Refer to page 121).
LV1/LV2/LV3
● Priority
Assign priority (1 (lowest) to 16 (highest) to hosts.
● Default Screen
Select a startup display to be displayed after logon from the
following.
CAM 1-16 (for the WJ-HD316)/CAM 1-9 (for the WJ-
HD309): Displays live images from the selected camera
channel on a single screen.
QUAD 1-4: Displays live images from the camera channels
1 - 4 on a 4-split screen.
QUAD 5-8: Displays live images from the camera channels
5 - 8 on a 4-split screen.
QUAD 9-12 (for the WJ-HD316)/CAM 9 (for the WJ-
HD309): Displays live images from the camera chan-
nels 9 - 12 on a 4-split screen. (When the WJ-HD309 is
used, live images from only camera channel 9 will be
displayed on the upper left screen of a 4-split screen.)
QUAD 13-16 (only for the WJ-HD316): Displays live
images from the camera channels 13 - 16 on a 4-split
screen.
7 SCREEN: Displays images on a 7-split screen.
9 SCREEN 1-9: Displays images from the camera channels
1 - 9 on a 9-split screen.
9 SCREEN 10-16 (only for the WJ-HD316): Displays
images from the camera channels 10 - 16 on a 9-split
screen.
10 SCREEN (only for the WJ-HD316): Displays images on
a 10-split screen.
13 SCREEN (only for the WJ-HD316): Displays images on
a 13-split screen.
16 SCREEN (only for the WJ-HD316): Displays images on
a 16-split screen.
SEQ: Images will be displayed in the sequential display.
● Camera Partitioning
Select a controllable range for each camera channel from
the following.
View/Operate: Displaying live images and operating cam-
era are possible.
View: Displaying live images is possible but cameras can-
not be operated .
--: Both displaying live images and operating camera are
impossible.
r
[User Edit] Correction of registered user infor-
mation
It is possible to edit registered user information.
Move the cursor to "User Name" and rotate the jog dial
to select the user name.
Registered information will be displayed.
Editing can be performed in the same way as registra-
tion. (Refer to page 119.)
Move the cursor to "EDIT" at the lower right on the menu
and press the SET button to complete editing.
t
[User Delete] Deletion of registered user
It is possible to delete a registered user.
Move the cursor to "User Name" and rotate the jog dial
to select the user name. Move the cursor to "DELETE"
and press the SET button.
The selected user will be deleted.
y
[Host Registration] Registration of PC (host)
accessible to this unit
Register host information for the PC that accesses the
unit via a network such as a LAN.
Move the cursor to "SET" at the lower right on the menu
and press the SET button to complete registration.
Schedule
System Comm Switcher
SETUP MENU
LIVE
Maintenance Recording Event
Display
Basic Setup
Time & Date
User Regist.
User Edit
User Delete
Host Regist.
Host Edit
Host Delete
User Level
Save/Load
■ User Name
DELETE
Schedule
System Comm Switcher
SETUP MENU
LIVE
Maintenance Recording Event
Display
Basic Setup
Time & Date
User Regist.
User Edit
User Delete
Host Regist.
Host Edit
Host Delete
User Level
Save/Load
CAM1
CAM2
CAM3
CAM4
CAM5
CAM6
CAM7
CAM8 CAM9
CAM10
CAM11
CAM12
CAM13
CAM14
CAM15
CAM16
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate View
View
View
--
--
--
--
--
■ User Name
■ User Password
■ Level
■ Priority
■ Default Screen
■ Camera Partitioning
LV1
16 SCREEN
SET
16
Schedule
System Comm Switcher
SETUP MENU
LIVE
Maintenance Recording Event
Display
Basic Setup
Time & Date
User Regist.
User Edit
User Delete
Host Regist.
Host Edit
Host Delete
User Level
Save/Load
■ Host IP Address
■ Level
■ Priority
■ Default Display
■ Camera Partitioning
LV1
000 . . . 000 000 000
CAM1
1
SET
CAM1
CAM2
CAM3
CAM4
CAM5
CAM6
CAM7
CAM8 CAM9
CAM10
CAM11
CAM12
CAM13
CAM14
CAM15
CAM16
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
View/Operate
