Page 135

135

[Screenshot 1]

The "TOP MENU" of the "HDD DISK MENU" will be dis-
played.

x Move the cursor to "MIRROR ON" using the arrows but-

ton (A B) and press the SET button.

[Screenshot 2]

The password entry window will be displayed.

c Enter the password for an administrator by rotating the

jog dial.
The camera selection buttons ([1] - [10/0] for the WJ-
HD316, [1] - [9], [0] for the WJ-HD309) are available to
enter numbers for password.
The same method is used to enter, insert and delete
characters as for attaching text information to images.
Refer to page 55.

v Move the cursor to "EXECUTE" using the arrows button

(C D) and press the SET button.

[Screenshot 3]

The confirmation dialog window will be displayed.

b Move the cursor to "OK" using the arrows button (A B)

and press the SET button.

→ Recovery of the hard disk will start when the unit is

in operation after the "HDD DISK MENU" is closed.

● Remove the Hard Disk Logically and

Reconfigure it (REMOVE)

It is possible to remove the hard disk logically (unmount)
without uninstalling (detaching) the hard disk physically. It
is recommended to remove the hard disk logically when the
hard disk of the unit or an extension unit is having trouble
(hard disk indicated with "*", "LOST" or "ERROR") and it is
necessary to remove it temporarily but not to stop opera-
tion.
Do the following to remove the hard disk logically.

z Turn on the power of this unit.

The image saying the system check has been complet-
ed will be displayed.
Press the SET button after the image is displayed.

Note: When the hard disk is replaced or removed, the

"TOP MENU" of the "HDD DISK MENU" will be auto-
matically displayed.

[Screenshot 1]

The "TOP MENU" of the "HDD DISK MENU" will be dis-
played.

x Move the cursor to "REMOVE" using the arrows button

(A B) and press the SET button.

[Screenshot 2]

The password entry window will be displayed.

c Enter the password for an administrator by rotating the

→ The hard disk will be removed logically and the

confirmation window will be displayed.

Digital Disk Recorder

WJ-HD300

HDD DISK MENU
TOP MENU

FORMAT

MIRROR ON

REMOVE

RESTART

EXIT

MIRROR OFF

Close the information of recording areas : [SETUP/ESC] OK : [SET]

120GB M

120GB

*(120GB)

ADD (120GB)

120GB

LOST

MAIN

EXT7

EXT6

EXT5

EXT4

EXT3

EXT2

EXT1

120GB M

120GB

*(ERROR)

ADD (ERROR)

120GB

Enter the password.

EXECUTE

CANCEL

Digital Disk Recorder

WJ-HD300

HDD DISK MENU
TOP MENU

FORMAT

MIRROR ON

REMOVE

RESTART

EXIT

MIRROR OFF

Close the information of recording areas : [SETUP/ESC] OK : [SET]

120GB M

120GB

*(120GB)

ADD (120GB)

120GB

LOST

MAIN

EXT7

EXT6

EXT5

EXT4

EXT3

EXT2

EXT1

120GB M

120GB

*(ERROR)

ADD (ERROR)

120GB

Enter the password.

EXECUTE

CANCEL

Digital Disk Recorder

WJ-HD300

HDD DISK MENU
TOP MENU

FORMAT

MIRROR ON

REMOVE

RESTART

EXIT

MIRROR OFF

Close the information of recording areas : [SETUP/ESC] OK : [SET]

120GB M

120GB

*(120GB)

ADD (120GB)

120GB

LOST

MAIN

EXT7

EXT6

EXT5

EXT4

EXT3

EXT2

EXT1

120GB M

120GB

*(ERROR)

ADD (ERROR)

120GB

CANCEL

Mirror "ON" in main unit.

Digital Disk Recorder

WJ-HD300

HDD DISK MENU
TOP MENU

FORMAT

MIRROR ON

REMOVE

RESTART

EXIT

MIRROR OFF

Close the information of recording areas : [SETUP/ESC] OK : [SET]

120GB M

120GB

*(120GB)

ADD (120GB)

120GB

LOST

MAIN

EXT7

EXT6

EXT5

EXT4

EXT3

EXT2

EXT1

120GB M

120GB

*(ERROR)

ADD (ERROR)

120GB

Digital Disk Recorder

WJ-HD300

HDD DISK MENU
TOP MENU

FORMAT

MIRROR ON

REMOVE

RESTART

EXIT

MIRROR OFF

Close the information of recording areas : [SETUP/ESC] OK : [SET]

120GB M

120GB

*(120GB)

ADD (120GB)

120GB

LOST

MAIN

EXT7

EXT6

EXT5

EXT4

EXT3

EXT2

EXT1

120GB M

120GB

*(ERROR)

ADD (ERROR)

120GB
