149
Setup Menu Setup Item Parameter Default Setting
Event
Event Setup Alarm Output OFF/1 s/2 s/...../30 s/40 s/50 s/1 m/
2 m/...../5 m/EXT
VMD: OFF
Video Loss: 2 s
Terminal Command Alarm: 2 s
Output Terminal HD316: TRM1/TRM2/...../TRM16
HD309: TRM1/TRM2/...../TRM9
Buzzer OFF/1 s/2 s/...../30 s/40 s/50 s/1 m/ VMD: OFF
2 m/...../5 m/EXT Video Loss: 2 s
Terminal Command Alarm: 2 s
Monitor1 Action HD316: OFF/CAM1/CAM2/...../CAM16 VMD: OFF
HD309: OFF/CAM1/CAM2/...../CAM9 Video Loss: Camera channel with a video
loss occurrence
Terminal Command Alarm: Same number
for camera channel number and alarm
number
Monitor2 Action HD316: OFF/CAM1/CAM2/...../CAM16 VMD: OFF
HD309: OFF/CAM1/CAM2/...../CAM9 Video Loss: Camera channel with a video
loss occurrence
Terminal Command Alarm: Same number
for camera channel number and alarm
number
VMD Setup (SETUP AREA) - -
(SETUP ALL AREA) - -
(DELETE AREA) - -
(DELETE ALL AREA) - -
(SENSITIVITY) - -
(VMD MODE) - -
(EXIT) - -
Alarm Setup Alarm Auto Reset OFF/1 s/2 s/...../30 s/40 s/50 s/1 m/2 m/3 m/
4 m/5 m
OFF
Alarm Disarm Time 2 s/3 s/...../10 s 2 s
Terminal Setup Terminal Setup N.O./N.C. N.O.
Schedule
Time Table Period 12:00AM to 12:00AM 12:00AM to 12:00AM (Everyday/Time
zone1)
--:-- to --:-- (Except above)
REC PROG PROG1/PROG2/PROG3/PROG4 PROG1
EVENT PROG PROG1/PROG2/PROG3/PROG4 PROG1
FTP SEND BY PERIODIC ON/OFF OFF
TIMER
ERROR REPORT MAIL ON/OFF OFF
WARNING REPORT MAIL ON/OFF OFF
NW BANDWIDTH CONTROL OFF/32kbps/64kbps/128kbps/256kbps/ OFF
512kbps/1024kbps/2Mbps/5Mbps/10Mbps
Resolution FRAME 3D ON/FRAME 3D OFF/FIELD/FRAME FIELD
REC PROGRAM RATE OFF/2 ips/3 ips/5 ips/6 ips/7.5 ips/10 ips/ Manual REC: 15 ips
15 ips/30 ips/60 ips Schedule REC: 15 ips
Event REC: 30 ips
RATE OFF/AUTO/0.1 ips/0.2 ips/0.3 ips/0.4 ips/ MANUAL: AUTO
0.5 ips/1 ips/2 ips/3 ips/5 ips/6 ips/7.5 ips/ SCHEDULE: AUTO
10 ips/15 ips/30 ips/60 ips EVENT (PRE): 1 ips
EVENT (POST): 1 ips
QUALITY SFA/SFB/FQA/FQB/NQA/NQB/EXA/EXB SFA
DURATION (TIME for the unit) 1 s/2 s/...../10 s/20 s/30 s/1 m/2 m,/...../ EVENT (PRE): 10 s
10 m/20 m/...../60 m/MANUAL/CONTINUE EVENT (POST): 30 s
