FastTrak100 User Manual
25
1. After assigning the drives to a Mirroring array, press keys to Save
your selection. The window below will appear.
Do you want the disk image to be duplicated to another? (Yes/No)
Y - Create and Duplicate
N - Create Only
2. Press “Y” for the Create and Duplicate option. The window below will appear
asking you to select the Source drive to use. FastBuild will copy all data from
the Source drive to the Target drive.
Source Disk
Channel:ID Drive Model Capacity (MB)
Target Disk
Channel:ID Drive Model Capacity (MB)
[Please Select A Source Disk]
Channel:ID Drive Model Capacity (MB)
1 :Master QUANTUMCR8.4A 8063
2 :Master QUANTUMCR8.4A 8063
[ ↑ ] Up [ ↓ ] [ESC] Exit [Ctrl-Y] Save
3. Use the arrow keys to choose which drive contains the existing data to be
copied.
WARNING: All target drive data will be erased. Make sure you choose
the correct drive.
4. Press [Ctrl-Y] keys to Save selection and start duplication. The following
confirmation screen will appear.
Start to duplicate the image . . .
Do you want to continue? (Yes/No)
Y – Continue N - Abort
5. Select “Y” to continue. If you choose “N” , you will be returned to step 1.
6. Once “Y” is selected, the following progress screen will appear. The process
will take a few minutes.
Please Wait While Duplicating The Image
10%
Complete
