FastTrak100 User Manual
23
Selecting Array Type
1. Under the Definition section of this menu, highlight the Array # for which you
want to assign a RAID level.
2. Use the [Space] key to cycle through three array types: Performance (RAID 0
Striping), Security (RAID 1 Mirroring, RAID 0+1 Striping/Mirroring (for 4
drives ), or Capacity (Spanning). See page 65 about RAID levels.
FastBuild (tm) Utility 1.xx (c) 1995-2000 Promise Technology, Inc.
[ Define Array Definition Menu ]
Array No RAID Mode
Total Drv
Capacity(MB) Status
Array 1 Stripe
2
16126 Functional
Stripe Block: 64 KB
[ Drive Assignments ]
Channel:ID
Drive Model
Capacity (MB) Assignment
1 : Master
QUANTUMCR8.4A
8063
Y
1 : Slave
QUANTUMCR8.4A
8063
N
2 : Master
QUANTUMCR8.4A
8063
Y
[ Keys Available ]
[
↑
] Up [
↓
] Down [ESC] Exit [Space] Select [Ctrl-Y] Save
Selecting Stripe Block
For RAID 0 Striped arrays only, you may manually select the “stripe block size.”
Use the Spacebar to scroll through choices progressing as follows (1, 2, 4, 8 ,
16 . . . 1024).
The size selected affects how FastTrak100 sends and retrieves data blocks from
the drives. You will need to perform your own testing to determine how the data
block size is affecting your particular use of the array. In general, a larger block
size is better when handling large data transfers (such as in A/V editing or graphics)
while a smaller block size is better when handling e-mail and other common server
data. The default is 64K.
Assigning Drive(s) to Array
1. Under the [ Drive Assignments ] section, highlight a drive using the [
↑
] Up [
↓
]
keys.
2. With the [Space] bar key, change the Assignable option to “Y” to add the
drive to the disk array.
3. Press
selected, the following scenarios will take place:
