FastTrak100 User Manual

Viewing Drive Assignments

The View Drive Assignments <2> option in the Main Menu displays whether drives
are assigned to a disk arrays or are unassigned.

Under the “Assignment” column, drives are labeled with their assigned disk array
or shown as “Free” if unassigned. Such “Free” drives can be used for a future
array or used as a spare drive when a drive fails in a mirrored array. Unassigned
drives are not accessible by the OS. The menu also displays the data transfer
mode that relates to speed used by each drive (U5 refers to 100MB/sec transfers,
U4 refers to 100MB/sec transfers, etc...)

[ View Drive Assignments ]

Channel:ID Drive Model

Capacity(MB) Assignment Mode

1 : Master QUANTUMCR8.4A 8063 Array 1 U5
1 : Slave QUANTUMCR8.4A 8063

Free U5

2 : Master

QUANTUMCR8.4A 8063 Array 1 U5

[ Keys Available ]

[

↑

] Up [

↓

] Down [ESC] Exit Mode (U=UDMA, P=PIO, D=DMA)
