COMSPHERE 3800Plus Modems
13-18 October 1998 3980-A2-GB30-40
S-Register List
S-registers affect the operating parameters of 3800Plus
modems. S-registers are only applicable when the DTE
Dialer Type configuration option is set for AT. (See &Mn
command.)
Table 13-2 lists all S-registers supported by 3800Plus
modems. The first column lists the S-register. The second
column lists all possible values for that register. The third
column lists the key sequence used to enter the equivalent
from the front panel. Use the reference in this column to
locate commands in Chapter 8,
Configure Branch if
further description is necessary.
S-Register Format
S-registers can be displayed and/or modified when the
modem is in Command mode. To display the value of an
S-register, issue the following command:
TYPE: ATSn?
Where: n is the register number
PRESS: Enter
To modify the value of an S-register, issue the
following command:
TYPE: ATSn=r
Where: n is the register number, and
r is the new value
PRESS: Enter
In Table 13-2, the value for n is listed in the S-register
column, and the value for r is listed in the Description
column.
Table 13-2
(1 of 15)
3800 Plus S-Registers
AT Command Description Front Panel Branch
S0 Auto-Answer Ring Number
Register determines number of rings the modem will count before
automatically answering a call.
Enter zero (0) if you do not want the modem to automatically answer any
calls. Otherwise, enter a value from 1–255 for the number of rings to count
before answering.
Factory setting is 1.
Configure\Edit\
Line Dialer
S2 AT Escape Character
Register determines ASCII value used for escape sequence to enter
Command mode from Data mode.
Enter a value from 1 to 127 for the escape character. Any value greater
than 127 causes the modem to disable the escape sequence. When the
escape sequence is disabled, the modem cannot return to Command
mode until the call is disconnected.
Factory setting is 43 (+ key).
Configure\Edit\
DTE Dialer
S3 Carriage Return Character
Register determines ASCII value used as the carriage return (Return key).
This character is used to end command lines and result codes.
Enter a value from 0 to 127 for the command end character.
Factory setting is 13 (carriage return key).
NOTE: The &W command used to save this change must be on a
separate line. This ensures both that the change is intentional,
and that the DTE can enter the new character.
Configure\Edit\
DTE Dialer
