Rj45 db9 male – Perle Systems Perle IOLAN DS1 User Manual
Page 192
EIA-232 Cabling Diagrams
192
IOLAN DS1/TS2 User’s Guide, Version 3.4
RJ45
DB9 Male
IOLAN RJ45
Terminal DB25
(DTE)
10-pin
8-pin
4
(DSR)
3
20 (DTR)
3
(RTS)
2
5 (CTS)
5
(TxD)
4
3 (RxD)
6
(RxD)
5
2 (TxD)
7
(GND)
6
7 (GND)
8
(CTS)
7
4 (RTS)
9
(DTR)
8
6 (DSR)
IOLAN DS1
DB9 Male
Terminal DB25
(DTE)
3 (TxD)
3 (RxD)
2 (RxD)
2 (TxD)
7 (RTS)
5 (CTS)
8 (CTS)
4 (RTS)
6 (DSR)
20 (DTR)
5 (GND)
7 (GND)
4 (DTR)
6 (DSR)
