● PC Setup
Graphics on the right column are from WindowsMe.
The factory default settings of the WJ-NT204 are as follows;
For a client PC to access WJ-NT204 factory default set-
tings, set the IP address of the PC to 192.168.0.XX (XX
means any number from 2 to 254 except 10).
1. Connect the WJ-NT204 to the PC.
2. Change the PC’s TCP/IP to match the factory default
settings of the WJ-NT204.
If your PC runs on WindowsMe, proceed as follows:
(1) Click the Start button, point to settings , and then
click Control Panel .
(2) Double-click Network .
(3) In the Network dialog box, click the Configuration
tab.
(4) Choose TCP/IP , and then click the [Properties]
button to display the TCP/IP Properties dialog
box.
(5) Specify an IP address as follows:
IP Address: 192.168.0.9
Subnet Mask: 255.255.255.0
IP address 192.168.0.10
Netmask 255.255.255.0
Default gateway 0. 0. 0. 0.
