TROUBLESHOOTING & REPAIR

F-12

F-12

POWER WAVE 450

TROUBLESHOOTING GUIDE

Observe Safety Guidelines

detailed in the beginning of this manual.

CAUTION

If for any reason you do not understand the test procedures or are unable to perform the test/repairs safely, con-
tact the Lincoln Electric Service Department for electrical troubleshooting assistance before you proceed. Call 1-
800-833-9353.

PROBLEMS
(SYMPTOMS)

POSSIBLE AREAS OF
MISADJUSTMENT(S)

RECOMMENDED
COURSE OF ACTION

FUNCTION PROBLEMS

The voltage and or wire feed
speed will not adjust to user satis-
faction.

1. Certain limits may have been

imposed on the welding para-
meters. Refer to the Limits
Overlay section of this manual.

NONE

The Dual Procedure overlay is
installed, and the user cannot
change from procedure “A” to
procedure “B” or vice versa.

1. Check for proper installation of

the Dual Procedure overlay.

2. Check the Dual Procedure Gun

Trigger or separate dual proce-
dure switch.

1. Perform the Serial Loop

Wiring Harness Test.

The voltage and or wire feed
speed can be adjusted on the
wire feeder, but the changes are
not shown on the Power Wave
display.

1. When the Limits Overlay or the

Setup Overlay is installed in
the Power Wave, the machine
and wire feeder displays do
not match. These overlays
cannot be used for welding.

2. If two wire feeders are con-

nected to the Power Wave,
only one of the feeder’s set-
tings can be displayed on the
Power Wave at one tme. Pull
the trigger of the wire feeder
whose settings you want dis-
played on the Power Wave.

1. Try the other wire feeder

receptacle. If the problem is
solved, the initial receptacle or
associated wiring is faulty.

2. If the problem persists with

both wire feeder receptacles,
check or replace the wire feed-
er and control cable.

3. If the wire feeder and control

cable are OK, then perform the
Serial Loop Wiring Harness
Test.

4. The display board may be

faulty. Replace and perform
voltage calibration.

5. The control board may be

faulty. Replace and perform
voltage calibration and current
calibration.
