ELECTRICAL DIAGRAMS
G-24
G-24
POWER WAVE 450
1
2
3
4
5
6
7
8
9
DCD
RD
TD
DTR
GND
DSR
RTS
CTS
RI
2
3
4
5
6
7
8
20
22RI
TD
RD
RTS
CTS
DSR
GND
DCD
DTR
1
1
2
3
4
5
6
7
8
9
#302
#306
#303
#307
9 PIN
FROM PC
NULL
MODEM
CABLE
RS 232
POWER WAVE
INTERNAL WIRING
J17 MOLEX
DISPLAY BOARD
CONNECTOR
POWER WAVE RS 232 CONNECTIONS
