WATER COOLER DISASSEMBLY
Service and repair should be performed by only Lincoln Electric factory trained personnel.
Unauthorized repairs performed on this equipment may result in danger to the technician or
machine operator and will invalidate your factory warranty. For your safety and to avoid elec-
trical shock, please observe all safety notes and precautions detailed throughout this manual.
If for any reason you do not understand the test procedures or are unable to perform the
test/repairs safely, contact the Lincoln Electric Service Department for electrical trou-
bleshooting assistance before you proceed. Call 1-800-833-9353 (WELD).
DESCRIPTION
The following procedure will aid the technician in disassembly of the machine water cooler
assembly for maintenance or part replacement for early model coolers.
MATERIALS NEEDED
Phillips head screw driver
Pliers
3/4" Open end wrench
5/16" Box wrench
WARNING
TROUBLESHOOTING & REPAIR
F-161 F-161
POWER WAVE 450
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Section TOC
Retur
n to Master TOC
Retur
n to Master TOC
Retur
n to Master TOC
Retur
n to Master TOC
This procedure takes approximately 60 minutes to perform.
