3000i Installation Guide
43
Appendix C: Connecting 19" Rack-Mount
Equipment to the Projector Platform
Use the provided clip-on nuts to secure the rack-mount equipment to the sides of the projector
platform, just below the projector itself. The projector platform can accommodate rack-mount
equipment with a width of 19" (48.3 cm).
To connect rack-mount equipment to the projector platform
1
Attach the provided clip-on nuts (located in the accessory kit) to the sides of the projector
platform (as required).
2
Connect your rack-mount equipment to the clip-on nuts using 10-32 x ½" fasteners (not
provided).
Clip-on nuts
19" rack-mount equipment
