3000i Installation Guide
37
Appendix A: Disassembling the 3000i
Disassembling your 3000i is only necessary if you need to move the cabinet through a low
doorway, or if a cabinet component requires replacement or repair.
NOTE: Two people are required to perform these procedures safely.
To remove the interactive whiteboard
1 Loosen the four captive fasteners on the back corners of the interactive whiteboard using a
Phillips  No. 2 screwdriver. Start with the two bottom fasteners; then loosen the two at the
top (you may require a step stool to reach these fasteners).
NOTE: Maintain constant pressure on the screwdriver to avoid damaging the screw holes.
NOTE: Even after the captive fasteners have been completely loosened, the interactive
whiteboard will remain suspended on two keyhole slots near the top of the cabinet.
Corner Captive
Fasteners
