3000i Installation Guide
28
Connecting an External Monitor or Projector
To direct the RGB output from the internal computer or guest laptop to an
external projector or monitor
Connect an HD DB15 video cable (not provided) from the external projector or monitor to
the Video OUT port in the Connection Panel. This connection is for RGB output only.
Computer 2 Inputs
Outputs
S-Video
Printer / Network
Auxiliary
Inputs
S-Video
Video OUT
HD DB15 Video Cable
External Projector
