3000i Installation Guide
11
Removing the Rear Access Panel
You must remove the rear access panel before installing your internal computer. Once you’ve
powered on the projector and internal computer, it’s advisable to replace the rear access panel
−
as well as lock the cabinet front doors
− as a security precaution.
To remove the rear access panel
1 Loosen the two captive thumbscrews at the top of the rear access panel.
2 Rotate the top of the rear access panel toward you and then pull it upwards, releasing it
from the cabinet.
Captive Thumbscrews
Rear Access Panel
