DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
334 of 344
Figure 13-18. Transmit-Side Timing, Elastic Store Enabled
t
F
t
R
TSYSCLK
TSERI
TCHCLK
t
t
SL
t
SH
SP
TSSYNC
TCHBLK
t D3
tD3
t
t
tSU
HD
SU
tHD
NOTE 1: TSERI IS ONLY SAMPLED ON THE FALLING EDGE OF TSYSCLK WHEN THE TRANSMIT-SIDE ELASTIC STORE IS ENABLED.
NOTE 2: TCHCLK AND TCHBLK ARE SYNCHRONOUS WITH TSYSCLK WHEN THE TRANSMIT-SIDE ELASTIC STORE IS ENABLED.
Figure 13-19. Transmit Line Interface Timing
TDCLKO
TPOSO, TNEGO
t DD
t
F
t
R
TDCLKI
TPOSI, TNEGI
t
t
LL
t
LH
LP
tHD
tSU
