DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
126 of 344
A
DD
R
N
AME
B
IT 7
B
IT 6
B
IT 5
B
IT 4
B
IT 3
B
IT 2
B
IT 1
B
IT 0
h
01A
h
TR.SR3
LSPARE LDN LUP LOTC LORC V52LNK RDMA RRA
01B
h
TR.IMR3
LSPARE LDN LUP LOTC LORC V52LNK RDMA RRA
01C
h
TR.SR4
RAIS-CI RSA1 RSA0 TMF TAF RMF RCMF RAF
01D
h
TR.IMR4
RAIS-CI RSA1 RSA0 TMF TAF RMF RCMF RAF
01E
h
TR.SR5
— — TESF TESEM TSLIP RESF RESEM RSLIP
01F
h
TR.IMR5
— — TESF TESEM TSLIP RESF RESEM RSLIP
020
h
TR.SR6
— TMEND RPE RPS RHWM RNE TLWM TNF
021
h
TR.IMR6
— TMEND RPE RPS RHWM RNE TLWM TNF
022
h
TR.SR7
— TMEND RPE RPS RHWM RNE TLWM TNF
023
h
TR.IMR7
— TMEND RPE RPS RHWM RNE TLWM TNF
024
h
TR.SR8
— — BOCC RFDLAD RFDLF TFDLE RMTCH RBOC
025
h
TR.IMR8
— — BOCC RFDLAD RFDLF TFDLE RMTCH RBOC
026
h
TR.SR9
— BBED BBCO BEC0 BRA1 BRA0 BRLOS BSYNC
027
h
TR.IMR9
— BBED BBCO BEC0 BRA1 BRA0 BRLOS BSYNC
028
h
TR.PCPR
RSAOICS RSRCS RFCS BRCS THSCS PEICS TFCS BTCS
029
h
TR.PCDR1
CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
02A
h
TR.PCDR2
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
02B
h
TR.PCDR3
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
02C
h
TR.PCDR4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
02D
h
TR.INFO4
— — — — H2UDR H2OBT H1UDR H1OBT
02E
h
TR.INFO5
— — TEMPTY TFULL REMPTY PS2 PS1 PS0
02F
h
TR.INFO6
— — TEMPTY TFULL REMPTY PS2 PS1 PS0
030
h
TR.INFO7
CSC5 CSC4 CSC3 CSC2 CSC0 FASSA CASSA CRC4SA
031
h
TR.H1RC
RHR RHMS — — HDLCD — — RSFD
032
h
TR.H2RC
RHR RHMS — — HDLCD — — RSFD
033
h
TR.E1RCR1
RSERC RSIGM RHDB3 RG802 RCRC4 FRC SYNCE RESYNC
034 TR.E1RCR2 — — — — — — — RCLA
