Maxim Integrated DS33R11 - Manual (Page 125)

DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
125 of 344
Table 11-8. T1/E1/J1 Transceiver Register Bit Map (Active when CST = 0)
A
DD
R
N
AME
B
IT 7
B
IT 6
B
IT 5
B
IT 4
B
IT 3
B
IT 2
B
IT 1
B
IT 0
000
h
TR.MSTRREG
— — — — TEST1 TEST0 T1/E1 SFTRST
001
h
TR.IOCR1
RSMS RSMS2 RSMS1 RSIO TSDW TSM TSIO ODF
002
h
TR.IOCR2
RDCLKIN
V
TDCLKIN
V
RSYNCINV TSYNCINV TSSYNCINV H100EN TSCLKM RSCLKM
003
h
TR.T1RCR1
— ARC OOF1 OOF2 SYNCC SYNCT SYNCE RESYNC
004
h
TR.T1RCR2
— RFM RB8ZS RSLC96 RZSE — RJC RD4YM
005
h
TR.T1TCR1
TJC TFPT TCPT TSSE GB7S TFDLS TBL TYEL
006
h
TR.T1TCR2
TB8ZS TSLC96 TZSE FBCT2 FBCT1 TD4YM Reserved TB7ZS
007
h
TR.T1CCR1
— — — TRAI-CI TAIS-CI TFM PDE TLOOP
008
h
TR.SSIE1-T1
TR.SSIE1-E1
CH8
CH7 CH7
CH6 CH6
CH5 CH5
CH4 CH4
CH3 CH3
CH2 CH2
CH1 CH1
UCAW
009
h
TR.SSIE2-T1
TR.SSIE2-E1
CH16
CH15 CH15
CH14 CH14
CH13 CH13
CH12 CH12
CH11 CH11
CH10 CH10
CH9
CH9
CH8
00A
h
TR.SSIE3-T1
TR.SSIE3-E1 CH24
CH22 CH23
CH21 CH22
CH20 CH21
CH19 CH20
CH18 CH19
CH17 CH18
CH16 CH17
LCAW
00B
h
TR.SSIE4
CH30 CH29 CH28 CH27 CH26 CH25 CH24 CH23
00C
h
TR.T1RDMR1
CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
00D
h
TR.T1RDMR2
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
00E
h
TR.T1RDMR3
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
00F
h
TR.IDR
ID7 ID6 ID5 ID4 ID3 ID2 ID1 ID0
010
h
TR.INFO1
RPDV TPDV COFA 8ZD 16ZD SEFE B8ZS FBE
011
h
TR.INFO2
BSYNC BD TCLE TOCD RL3 RL2 RL1 RL0
012
h
TR.INFO3
— — — — — CRCRC FASRC CASRC
013
h
Reserved
— — — — — — — —
014
h
TR.IIR1
SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1
015
h
TR.IIR2
— — — — — — — SR9
016
h
TR.SR1
ILUT TIMER RSCOS JALT LRCL TCLE TOCD LOLITC
017
h
TR.IMR1
ILUT TIMER RSCOS JALT LRCL TCLE TOCD LOLITC
018
h
TR.SR2
RYELC RUA1C FRCLC RLOSC RYEL RUA1 FRCL RLOS
019
TR.IMR2 RYELC RUA1C FRCLC RLOSC RYEL RUA1 FRCL RLOS
