DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
156 of 344
Register Name: LI.TPCR0
Register Description: Transmit Packet Count Byte 0
Register Address: 0CCh
Bit
# 7 6 5 4 3 2 1 0
Name TPC7 TPC6 TPC5 TPC4 TPC3 TPC2 TPC1 TPC0
Default 0 0 0 0 0 0 0 0
Bits 0 – 7: Transmit Packet Count (TPC[7:0]) – Eight bits of 24 bit value. Register description below.
Register Name:
LI.TPCR1
Register Description: Transmit Packet Count Byte 1
Register Address: 0CDh
Bit
# 7 6 5 4 3 2 1 0
Name TPC15 TPC14 TPC13 TPC12 TPC11 TPC10 TPC9 TPC8
Default 0 0 0 0 0 0 0 0
Bits 0 – 7: Transmit Packet Count (TPC[15:8]) – Eight bits of 24 bit value. Register description below.
Register Name:
LI.TPCR2
Register Description: Transmit Packet Count Byte 2
Register Address: 0CEh
Bit
# 7 6 5 4 3 2 1 0
Name TPC23 TPC22 TPC21 TPC20 TPC19 TPC18 TPC17 TPC16
Default 0 0 0 0 0 0 0 0
Bits 0 – 7: Transmit Packet Count (TPC[23:16]) – These twenty-four bits indicate the number of packets
extracted from the Transmit FIFO and output in the outgoing data stream.
