DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver

257 of 344

Register Name:

TR.LIC2

Register Description:

Line Interface Control 2

Register Address:

79h


Bit

# 7 6 5 4 3 2 1 0

Name ETS LIRST IBPV TUA1

JAMUX — SCLD CLDS

Default

0 0 0 0 0 0 0 0


Bit 7: E1/T1 Select (ETS)

0 = T1 mode selected
1 = E1 mode selected


Bit 6: Line Interface Reset (LIRST).
Setting this bit from a 0 to a 1 initiates an internal reset that resets the clock
recovery state machine and recenters the jitter attenuator. Normally this bit is only toggled on power-up. Must be
cleared and set again for a subsequent reset.

Bit 5: Insert BPV (IBPV).
A 0-to-1 transition on this bit causes a single BPV to be inserted into the transmit data
stream. Once this bit has been toggled from a 0 to a 1, the device waits for the next occurrence of three
consecutive 1s to insert the BPV. This bit must be cleared and set again for a subsequent error to be inserted.

Bit 4: Transmit Unframed All Ones (TUA1).
The polarity of this bit is set such that the device transmits an all-
ones pattern on power-up or device reset. This bit must be set to a 1 to allow the device to transmit data. The
transmission of this data pattern is always timed off of the JACLK.

0 = transmit all ones at TTIP and TRING
1 = transmit data normally


Bit 3: Jitter Attenuator Mux (JAMUX).
Controls the source for JACLK.

0 = JACLK sourced from MCLK (2.048MHz or 1.544MHz at MCLK)
1 = JACLK sourced from internal PLL (2.048MHz at MCLK)


Bit 1: Short-Circuit Limit Disable (ETS = 1) (SCLD). Controls the 50mA (RMS) current limiter.

0 = enable 50mA current limiter
1 = disable 50mA current limiter


Bit 0: Custom Line Driver Select (CLDS). Setting this bit to a 1 redefines the operation of the transmit line driver.
When this bit is set to a 1 and TR.LIC1.5 = TR.LIC1.6 = TR.LIC1.7 = 0, the device generates a square wave at the
TTIP and TRING outputs instead of a normal waveform. When this bit is set to a 1 and TR.LIC1.5 = TR.LIC1.6 =
TR.LIC1.7

≠ 0, the device forces TTIP and TRING outputs to become open-drain drivers instead of their normal

push-pull operation. This bit should be set to 0 for normal operation of the device.
