DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
132 of 344
A
DD
R
N
AME
B
IT 7
B
IT 6
B
IT 5
B
IT 4
B
IT 3
B
IT 2
B
IT 1
B
IT 0
0C1
h
TR.TFDL
TFDL7 TFDL6 TFDL5 TFDL4 TFDL3 TFDL2 TFDL1 TFDL0
0C2
h
TR.RFDLM1
RFDLM7 RFDLM6 RFDLM5 RFDLM4 RFDLM3 RFDLM2 RFDLM1 RFDLM0
0C3
h
TR.RFDLM2
RFDLM7 RFDLM6 RFDLM5 RFDLM4 RFDLM3 RFDLM2 RFDLM1 RFDLM0
0C3
h
Reserved
— — — — — — — —
0C5
h
Reserved
— — — — — — — —
0C6
h
TR.RAF
Si 0 0 1 1 0 1 1
0C7
h
TR.RNAF
Si 1 A Sa4 Sa5 Sa6 Sa7 Sa8
0C8
h
TR.RSiAF
SiF0 SiF2 SiF4 SiF6 SiF8 SiF10 SiF12 SiF14
0C9
h
TR.RSiNAF
SiF1 SiF3 SiF5 SiF7 SiF9 SiF11 SiF13 SiF15
0CA
h
TR.RRA
RRAF1 RRAF3 RRAF5 RRAF7 RRAF9 RRAF11 RRAF13 RRAF15
0CB
h
TR.RSa4
RSa4F1 RSa4F3 RSa4F5 RSa4F7 RSa4F9 RSa4F11 RSa4F13 RSa4F15
0CC
h
TR.RSa5
RSa5F1 RSa5F3 RSa5F5 RSa5F7 RSa5F9 RSa5F11 RSa5F13 RSa5F15
0CD
h
TR.RSa6
RSa6F1 RSa6F3 RSa6F5 RSa6F7 RSa6F9 RSa6F11 RSa6F13 RSa6F15
0CE
h
TR.RSa7
RSa7F1 RSa7F3 RSa7F5 RSa7F7 RSa7F9 RSa7F11 RSa7F13 RSa7F15
0CF
h
TR.RSa8
RSa8F1 RSa8F3 RSa8F5 RSa8F7 RSa8F9 RSa8F11 RSa8F13 RSa8F15
0D0
h
TR.TAF
Si 0 0 1 1 0 1 1
0D1
h
TR.TNAF
Si 1 A Sa4 Sa5 Sa6 Sa7 Sa8
0D2
h
TR.TSiAF
TsiF0 TsiF2 TsiF4 TsiF6 TsiF8 TsiF10 TsiF12 TsiF14
0D3
h
TR.TSiNAF
TsiF1 TsiF3 TsiF5 TsiF7 TsiF9 TsiF11 TsiF13 TSiF15
0D4
h
TR.TRA
TRAF1 TRAF3 TRAF5 TRAF7 TRAF9 TRAF11 TRAF13 TRAF15
0D5
h
TR.TSa4
TSa4F1 TSa4F3 TSa4F5 TSa4F7 TSa4F9 TSa4F11 TSa4F13 TSa4F15
0D6
h
TR.TSa5
TSa5F1 TSa5F3 TSa5F5 TSa5F7 TSa5F9 TSa5F11 TSa5F13 TSa5F15
0D7
h
TR.TSa6
TSa6F1 TSa6F3 TSa6F5 TSa6F7 TSa6F9 TSa6F11 TSa6F13 TSa6F15
0D8
h
TR.TSa7
TSa7F1 TSa7F3 TSa7F5 TSa7F7 TSa7F9 TSa7F11 TSa7F13 TSa7F15
0D9
h
TR.TSa8
TSa8F1 TSa8F3 TSa8F5 TSa8F7 TSa8F9 TSa8F11 TSa8F13 TSa8F15
0DA
h
TR.TSACR
SiAF SiNAF RA Sa4 Sa5 Sa6 Sa7 Sa8
0DB
h
TR.BAWC
ACNT7 ACNT6 ACNT5 ACNT4 ACNT3 ACNT2 ACNT1 ACNT0
