DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
121 of 344
A
DDR
N
AME
B
IT 7
B
IT 6
B
IT 5
B
IT 4
B
IT 3
B
IT 2
B
IT 1
B
IT 0
114h LI.RSPCB0 RSPC7 RSPC6 RSPC5 RSPC4 RSPC3 RSPC2 RSPC1 RSPC0
115h LI.RSPCB1 RSPC15 RSPC14 RSPC13 RSPC12 RSPC11 RSPC10 RSPC9 RSPC8
116h LI.RSPCB2 RSPC23 RSPC22 RSPC21 RSPC20 RSPC19 RSPC18 RSPC17 RSPC16
118h LI.RBC0 RBC7 RBC6 RBC5 RBC4 RBC3 RBC2 RBC1 RBC0
119h LI.RBC1 RBC15 RBC14 RBC13 RBC12 RBC11 RBC10 RBC9 RBC8
11Ah LI.RBC2 RBC23 RBC22 RBC21 RBC20 RBC19 RBC18 RBC17 RBC16
11Bh LI.RBC3 RBC31 RBC30 RBC29 RBC28 RBC27 RBC26 RBC25 RBC24
11Ch LI.RAC0 REBC7 REBC6 REBC5 REBC4 REBC3 REBC2 REBC1 REBC0
11Dh LI.RAC1 REBC15 REBC14 REBC13 REBC12 REBC11 REBC10 REBC9 REBC8
11Eh LI.RAC2 REBC23 REBC22 REBC21 REBC20 REBC19 REBC18 REBC17 REBC16
11Fh LI.RAC3 REBC31 REBC30 REBC29 REBC28 REBC27 REBC26 REBC25 REBC24
120h
LI.RHPMUU - - - - - - - RPMUU
121h
LI.RHPMUS - - - - - - - RPMUUS
122h LI.RX86S - - - - SAPIHNE SAPILNE CNE ANE
123h LI.RX86LSIE - - - - SAPINE01IM SAPINEFEIM CNE3LIM ANE4IM
124h LI.TQLT TQLT7 TQLT6 TQLT5 TQLT4 TQLT3 TQLT2 TQLT1 TQLT0
125h LI.TQHT TQHT7 TQHT6 TQHT5 TQHT4 TQHT3 TQHT2 TQHT1 TQHT0
126h LI.TQTIE - - - - TFOVFIE TQOVFIE TQHTIE TQLTIE
127h LI.TQCTLS - - - - TFOVFLS TQOVFLS TQHTLS TQLTLS
Note: 0DEh–0FFh, 128h–13Fh are reserved.
