DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
171 of 344
Register Name:
LI.RHPMUU
Register Description:
Serial Interface Receive HDLC PMU Update Register
Register Address:
120h
Bit
# 7 6 5 4 3 2 1 0
Name - - - - - - -
RPMUU
Default
0 0 0 0 0 0 0 0
Bit 0: Receive PMU Update (RPMUU) This signal causes the receive cell/packet processor block performance
monitoring registers (counters) to be updated. A 0 to 1 transition causes the performance monitoring registers to be
updated with the latest data, and the counters reset (0 or 1). This update updates performance monitoring counters
for the Serial Interface.
Register Name:
LI.RHPMUS
Register Description:
Serial Interface Receive HDLC PMU Update Status Register
Register Address:
121h
Bit
# 7 6 5 4 3 2 1 0
Name - - - - - - -
RPMUUS
Default
0 0 0 0 0 0 0 0
Bit 0: Receive PMU Update Status (RPMUUS) This bit is set when the Transmit PMU Update is completed. This
bit is cleared when RPMUU is set to 0.
Register Name:
LI.RX86S
Register Description:
Receive X.86 Latched Status Register
Register Address:
122h
Bit
# 7 6 5 4 3 2 1 0
Name
- - - -
SAPIHNE
SAPILNE
CNE
ANE
Default
- - - - - - - -
Bit 3: SAPI High is not equal to
Latched Status (SAPIHNE) This latched status bit is set if
SAPIH is not equal to LI.TRX86SAPIH. This latched status bit is cleared upon read.
Bit 2: SAPI Low is not equal to
Latched Status (SAPILNE) This latched status bit is set if
SAPIL is not equal to LI.TRX86SAPIL. This latched status bit is cleared upon read.
Bit 1: Control is not equal to
(CNE) This latched status bit is set if the control field is not equal to
LI.TRX8C. This latched status bit is cleared upon read.
Bit 0: Address is not equal to
(ANE) This latched status bit is set if the X.86 Address field is not
equal to LI.TRX86A. This latched status bit is cleared upon read.
