DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
247 of 344
Register Name:
TR.TS1 to TR.TS12
Register Description: Transmit Signaling Registers (T1 Mode, ESF Format)
Register Address: 50h to 5Bh
(MSB) (LSB)
CH2-A CH2-B CH2-C CH2-D CH1-A CH1-B CH1-C CH1-D TS1
CH4-A CH4-B CH4-C CH4-D CH3-A CH3-B CH3-C CH3-D TS2
CH6-A CH6-B CH6-C CH6-D CH5-A CH5-B CH5-C CH5-D TS3
CH8-A CH8-B CH8-C CH8-D CH7-A CH7-B CH7-C CH7-D TS4
CH10-A CH10-B CH10-C CH10-D CH9-A CH9-B CH9-C CH9-D TS5
CH12-A CH12-B CH12-C CH12-D CH11-A CH11-B CH11-C CH11-D TS6
CH14-A CH14-B CH14-C CH14-D CH13-A CH13-B CH13-C CH13-D TS7
CH16-A CH16-B CH16-C CH16-D CH15-A CH15-B CH15-C CH15-D TS8
CH18-A CH18-B CH18-C CH18-D CH17-A CH17-B CH17-C CH17-D TS9
CH20-A CH20-B CH20-C CH20-D CH19-A CH19-B CH19-C CH19-D TS10
CH22-A CH22-B CH22-C CH22-D CH21-A CH21-B CH21-C CH21-D TS11
CH24-A CH24-B CH24-C CH24-D CH23-A CH23-B CH23-C CH23-D TS12
