DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver

216 of 344


Register Name:

TR.IMR1

Register Description:

Interrupt Mask Register 1

Register Address:

17h


Bit

# 7 6 5 4 3 2 1 0

Name ILUT TIMER

RSCOS

JALT LRCL TCLE TOCD

LOLITC

Default

0 0 0 0 0 0 0 0


Bit 7: Input Level Under Threshold (ILUT)

0 = interrupt masked
1 = interrupt enabled

Bit 6: Timer Event (TIMER)

0 = interrupt masked
1 = interrupt enabled

Bit 5: Receive Signaling Change-of-State Event (RSCOS)

0 = interrupt masked
1 = interrupt enabled


Bit 4: Jitter Attenuator Limit Trip Event (JALT)

0 = interrupt masked
1 = interrupt enabled


Bit 3: Line Interface Receive Carrier-Loss Condition (LRCL)

0 = interrupt masked
1 = interrupt enabled—generates interrupts on rising and falling edges


Bit 2: Transmit Current-Limit Exceeded Condition (TCLE)

0 = interrupt masked
1 = interrupt enabled—generates interrupts on rising and falling edges


Bit 1: Transmit Open-Circuit Detect Condition (TOCD)

0 = interrupt masked
1 = interrupt enabled—generates interrupts on rising and falling edges


Bit 0: Loss-of-Transmit Clock Condition (LOLITC)

0 = interrupt masked
1 = interrupt enabled—generates interrupts on rising and falling edges
