DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
229 of 344
Register Name:
TR.SR9
Register Description:
Status Register 9
Register Address:
26h
Bit
# 7 6 5 4 3 2 1 0
Name — BBED
BBCO
BEC0
BRA1
BRA0
BRLOS
BSYNC
Default
0 0 0 0 0 0 0 0
Bit 6: BERT Bit-Error Detected (BED) Event (BBED). A latched bit that is set when a bit error is detected. The
receive BERT must be in synchronization for it to detect bit errors. Cleared when read.
Bit 5: BERT Bit-Counter Overflow Event (BBCO). A latched bit that is set when the 32-bit BERT bit counter
(BBC) overflows. Cleared when read and is not set again until another overflow occurs.
Bit 4: BERT Error-Counter Overflow (BECO) Event (BECO). A latched bit that is set when the 24-bit BERT error
counter (BEC) overflows. Cleared when read and is not set again until another overflow occurs.
Bit 3: BERT Receive All-Ones Condition (BRA1). A latched bit that is set when 32 consecutive 1s are received.
Allowed to be cleared once a 0 is received. This is a double interrupt bit (Section
Bit 2: BERT Receive All-Zeros Condition (BRA0). A latched bit that is set when 32 consecutive 0s are received.
Allowed to be cleared once a 1 is received. This is a double interrupt bit (Section
Bit 1: BERT Receive Loss-of-Synchronization Condition (BRLOS). A latched bit that is set whenever the
receive BERT begins searching for a pattern. Once synchronization is achieved, this bit remains set until read. This
is a double interrupt bit (Section
Bit 0: BERT in Synchronization Condition (BSYNC). Set when the incoming pattern matches for 32 consecutive
bit positions. Refer to BSYNC in the TR.INFO2 register for a real-time version of this bit. This is a double interrupt
bit (Section
).
