DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
290 of 344
Register Name: TR.TSACR
Register Description: Transmit Sa Bit Control Register
Register Address: DAh
Bit
# 7 6 5 4 3 2 1 0
Name SiAF SiNAF RA Sa4 Sa5 Sa6 Sa7 Sa8
Default 0 0 0 0 0 0 0 0
Bit 7: International Bit in Align Frame Insertion Control Bit (SiAF)
0 = do not insert data from the TR.TSiAF register into the transmit data stream
1 = insert data from the TR.TSiAF register into the transmit data stream
Bit 6: International Bit in Nonalign Frame Insertion Control Bit (SiNAF)
0 = do not insert data from the TR.TSiNAF register into the transmit data stream
1 = insert data from the TR.TSiNAF register into the transmit data stream
Bit 5: Remote Alarm Insertion Control Bit (RA)
0 = do not insert data from the TR.TRA register into the transmit data stream
1 = insert data from the TR.TRA register into the transmit data stream
Bit 4: Additional Bit 4 Insertion Control Bit (Sa4)
0 = do not insert data from the TR.TSa4 register into the transmit data stream
1 = insert data from the TR.TSa4 register into the transmit data stream
Bit 3: Additional Bit 5 Insertion Control Bit (Sa5)
0 = do not insert data from the TR.TSa5 register into the transmit data stream
1 = insert data from the TR.TSa5 register into the transmit data stream
Bit 2: Additional Bit 6 Insertion Control Bit (Sa6)
0 = do not insert data from the TR.TSa6 register into the transmit data stream
1 = insert data from the TR.TSa6 register into the transmit data stream
Bit 1: Additional Bit 7 Insertion Control Bit (Sa7)
0 = do not insert data from the TR.TSa7 register into the transmit data stream
1 = insert data from the TR.TSa7 register into the transmit data stream
Bit 0: Additional Bit 8 Insertion Control Bit (Sa8)
0 = do not insert data from the TR.TSa8 register into the transmit data stream
1 = insert data from the TR.TSa8 register into the transmit data stream
Register Name: TR.BAWC
Register Description: BERT Alternating Word-Count Rate
Register Address: DBh
Bit # 7 6 5 4 3 2 1 0
Name ACNT7 ACNT6 ACNT5 ACNT4 ACNT3 ACNT2 ACNT1 ACNT0
Default
0 0 0 0 0 0 0 0
Bits 0 – 7: Alternating Word-Count Rate Bits 0 to 7 (ACNT0 to ACNT7). ACNT0 is the LSB of the 8-bit
alternating word-count rate counter.
