DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
284 of 344
Register Name: TR.RSa7
Register Description: Received Sa7 Bits
Register Address: CEh
Bit
# 7 6 5 4 3 2 1 0
Name RSa7F1 Rsa7F3 RSa7F5 RSa7F7 RSa7F9 RSa7F11 RSa7F13 RSa7F15
Default
0 0 0 0 0 0 0 0
Bit 7: Sa7 Bit of Frame 1(RSa4F1)
Bit 6: Sa7 Bit of Frame 3 (RSa7F3)
Bit 5: Sa7 Bit of Frame 5 (RSa7F5)
Bit 4: Sa7 Bit of Frame 7 (RSa7F7)
Bit 3: Sa7 Bit of Frame 9 (RSa7F9)
Bit 2: Sa7 Bit of Frame 11 (RSa7F11)
Bit 1: Sa7 Bit of Frame 13 (RSa7F13)
Bit 0: Sa7 Bit of Frame 15 (RSa7F15)
Register Name:
TR.RSa8
Register Description: Received Sa8 Bits
Register Address: CFh
Bit
# 7 6 5 4 3 2 1 0
Name RSa8F1 RSa8F3 RSa8F5 RSa8F7 RSa8F9 RSa8F11 RSa8F13 RSa8F15
Default 0 0 0 0 0 0 0 0
Bit 7: Sa8 Bit of Frame 1 (RSa8F1)
Bit 6: Sa8 Bit of Frame 3 (RSa8F3)
Bit 5: Sa8 Bit of Frame 5 (RSa8F5)
Bit 4: Sa8 Bit of Frame 7 (RSa8F7)
Bit 3: Sa8 Bit of Frame 9 (RSa8F9)
Bit 2: Sa8 Bit of Frame 11 (RSa8F11)
Bit 1: Sa8 Bit of Frame 13 (RSa8F13)
Bit 0: Sa8 Bit of Frame 15 (RSa8F15)
