DS33R11 Ethernet Mapper with Integrated T1/E1/J1 Transceiver
168 of 344
Register Name:
LI.RSPCB0
Register Description: Receive Size Violation Packet Count Byte 0 Register
Register Address: 114h
Bit
# 7 6 5 4 3 2 1 0
Name RSPC7 RSPC6 RSPC5 RSPC4 RSPC3 RSPC2 RSPC1 RSPC0
Default 0 0 0 0 0 0 0 0
Bits 0 - 7: Receive Size Violation Packet Count (RSPC [7:0]) Eight bits of a 24-bit value. Register description
below.
Register Name:
LI.RSPCB1
Register Description: Receive Size Violation Packet Count Byte 1 Register
Register Address: 115h
Bit
# 7 6 5 4 3 2 1 0
Name RSPC15 RSPC14 RSPC13 RSPC12 RSPC11 RSPC10 RSPC9 RSPC8
Default 0 0 0 0 0 0 0 0
Bits 0 - 7: Receive Size Violation Packet Count (RSPC [15:8]) Eight bits of a 24-bit value. Register description
below.
Register Name:
LI.RSPCB2
Register Description: Receive Size Violation Packet Count Byte 2 Registers
Register Address: 116h
Bit
# 7 6 5 4 3 2 1 0
Name RSPC23 RSPC22 RSPC21 RSPC20 RSPC19 RSPC18 RSPC17 RSPC16
Default 0 0 0 0 0 0 0 0
Bits 0 – 7: Receive Size Violation Packet Count (RSPC [23:16]) These twenty-four bits indicate the number of
packets received with a packet size violation (below minimum, above maximum, or noninteger number of bytes).
The byte count for these packets is included in the receive aborted byte count register REBCR.
